Battery Type

LiFePO4 (Lithium Iron Phosphate)

Cell Configuration

4S (4-series, 12.8V nominal, 14.6V max)

Charge Voltage

14.6V (3.65V per cell)

Discharge Voltage

10.0V–14.6V (2.5V–3.65V per cell)

Max Continuous Current

100A (Peak: 150A–200A)

Balance Function

Passive Balancing (Typically 30–100mA)

Overcharge Protection

3.65±0.05V per cell

Over-Discharge Protection

2.0±0.05V per cell

Overcurrent Protection

100A–120A (Adjustable in some models)

Short-Circuit Protection

Yes (Auto-recovery or latch-off)

Temperature Protection

NTC Thermistor (Optional)

Balance Current

30–100mA (Passive)

Operating Temperature

-20°C to +60°C

PCB Size

~70mm x 50mm (Varies by manufacturer)

Wire Gauge

8–10AWG recommended for high current
