SK10 SH10 Vertical Type Holder 10mm Linear Rail Shaft End Support قاعدة تثبيت محور املس شكل مستطيل
|
Description |
|
|
Model Designation |
SK10 / SH10 (These are common
designations, often interchangeable between manufacturers) |
|
Compatible Shaft Diameter (d) |
10mm (designed to securely hold
and support a 10mm diameter linear shaft/rod) |
|
Type |
Vertical Type Holder / Fixed End
Support |
|
Material |
Aluminum Alloy (Typically anodized
in silver or black for corrosion resistance and aesthetic finish) |
|
Mounting Orientation |
Vertical mounting (designed to be
bolted onto a flat surface, with the shaft clamping upwards from the base) |
|
Overall Dimensions (approx.) |
|
|
- Width (W) |
~42mm |
|
- Height (H) |
~28mm |
|
- Length/Base (L) |
~25mm |
|
- Mounting Hole Spacing (A) |
~32mm - 34mm |
|
- Mounting Hole Diameter (D) |
~5.5mm (for M5 screws) |
|
Shaft Clamping Method |
Split Clamp Design with Set
Screw(s) (Usually one or two M4/M5 set screws are used to compress the split
in the aluminum body, firmly gripping the shaft.) |
