Model Designation

SHF12 (A widely recognized designation across manufacturers)

Compatible Shaft Diameter (d)

12mm (Specifically designed to firmly clamp and support 12mm diameter linear shafts/rods)

Type

Horizontal Type Holder / Flanged Shaft Support / Fixed End Support

Material

Aluminum Alloy (Typically anodized, usually in silver or sometimes black, providing good corrosion resistance and a durable finish)

Mounting Orientation

Horizontal mounting (Designed to be bolted onto a flat surface, with the shaft extending horizontally, parallel to the mounting plane)

Overall Dimensions (approx.)

- Length (L)

~47mm

- Width (W)

~28mm

- Height (H)

~12mm - 13.2mm (This refers to the overall height from the base to the top of the clamping mechanism)

- Mounting Hole Spacing (A)

~36mm (Center-to-center distance of the mounting holes on the base flange)

- Mounting Hole Diameter (D)

~5.5mm (Suitable for M5 screws, which are the common fasteners used for mounting)

Shaft Clamping Method

Split Clamp Design with Set Screw(s) (Typically one or two M4 or M5 grub/set screws are used to tighten the split in the aluminum body, creating a strong friction clamp around the 12mm shaft)
