Model Designation

SHF20

Compatible Shaft Diameter (d)

20mm (Specifically designed to firmly clamp and support 20mm diameter linear shafts/rods)

Type

Horizontal Type Holder / Flanged Shaft Support / Fixed End Support

Material

Aluminum Alloy (Typically anodized, usually in silver or sometimes black, for enhanced corrosion resistance and a durable, aesthetic finish)

Mounting Orientation

Horizontal mounting (Designed to be bolted onto a flat surface, with the shaft extending horizontally, parallel to the mounting plane)

Overall Dimensions (approx.)

- Length (L)

~60mm

- Width (W)

~37mm (Height from base to top of clamping mechanism)

- Height (H)

~20mm (Thickness of the base plate)

- Mounting Hole Spacing (A)

~48mm (Center-to-center distance of the mounting holes on the base flange)

- Mounting Hole Diameter (D)

~7mm (Suitable for M6 screws, which are commonly used for mounting these larger supports)

Shaft Clamping Method

Split Clamp Design with Set Screw(s) (Typically secured with one or two M5 or M6 grub/set screws that tighten the split in the aluminum body, creating a strong friction clamp around the 20mm shaft)
