42HD6021-03 NEMA17 Stepper Motor 47mm Long, 1.5A with 500mm Cable ستيبر موتور
|
Specification |
|
|
Motor Type |
Bipolar 4-wire Stepper |
|
Frame Size |
NEMA 17 (42.3×42.3mm) |
|
Body Length |
47mm |
|
Step Angle |
1.8° (200 steps/revolution) |
|
Current Rating |
1.5A/phase |
|
Voltage Rating |
Typically 12-24V (depends on
driver) |
|
Resistance/Phase |
~2.8Ω (calculated from V=IR) |
|
Inductance |
~3.0mH/phase (typical for this
size) |
|
Holding Torque |
~40N·cm (approx. 56oz·in) |
|
Detent Torque |
~2.2N·cm |
|
Rotor Inertia |
~54g·cm² |
|
Weight |
~350g |
|
Cable Length |
500mm (4-wire) |
|
Connector |
Usually bare wire ends (may vary
by supplier) |
|
Insulation Class |
Class B |
|
Ambient Temperature |
-20°C to +50°C |
