TP5100 4.2v 8.4v Single Double Lithium Battery Charge Management Li-ion Battery Compatible 2A Charging Board دائرة حماية شحن بطاريات ليثيوم مفردة ومزدوجة
|
Specification |
|
|
Input Voltage |
4.5V - 12V (Recommended: 5V-9V) |
|
Charge Voltage |
4.2V (1-cell) / 8.4V (2-cell)
(Auto-detection) |
|
Charge Current |
Adjustable (Up to 2A Max) |
|
Battery Compatibility |
Single/Dual Li-ion/Li-Po
(3.7V/4.2V per cell) |
|
Charging Mode |
CC (Constant Current) + CV
(Constant Voltage) |
|
Charge Status Indication |
LED (Red = Charging, Green = Fully
Charged) |
|
Protection Features |
Overcharge Protection,
Short-Circuit Protection, Thermal Protection |
|
Efficiency |
Up to 90% (Depending on Input
Voltage) |
|
Dimensions |
Approx. 36mm x 17mm (Varies by
manufacturer) |
|
Operating Temperature |
-40°C to +85°C |
|
Adjustable Current |
Yes (Via resistor modification) |
