Model Number

AD20P-0510A

Pump Type

Brushless DC Submersible Water Pump

Rated Voltage

DC 5V

Rated Current

Typically 100mA - 200mA (exact value may vary)

Power Consumption

Approximately 1W

Max Water Head

1 Meter (100 cm)

Max Flow Rate

120 L/H (Liters per Hour)

Noise Level

Ultra-Quiet, typically < 35dB - 40dB

Motor Type

Brushless DC Motor (for long lifespan and quiet operation)

Lifespan

Typically > 10,000 - 20,000 hours (due to brushless design)

Cable Length

1.5 Meters

Submersible

Yes, fully submersible (IP68 rating common)

Outlet Diameter

Typically 8mm (Inner Diameter)

Inlet Diameter

Typically 8mm (Inner Diameter)

Pump Body Material

High-strength engineering plastics (e.g., ABS, PC)

Dimensions (approx.)

Compact, typically around 43mm (length) x 23mm (width) x 30mm (height)

Weight (approx.)

30g - 50g (excluding cable)

Operating Temperature

Water: 0°C - 60°C (typical)

Features

Ultra-quiet operation, long lifespan, low power consumption, small size, high efficiency, can be used for both fresh and salt water.

Typical Applications

Small desktop fountains, pet water dispensers, aquariums, hydroponics, mini cooling systems, DIY crafts, coffee machines, medical devices (non-critical).
