Feature

Description

Purpose

A versatile, automatic component tester for identifying, measuring, and analyzing various electronic components like transistors, resistors, capacitors, inductors, diodes, and more.

Display

High-resolution color LCD display (e.g., 160x128 pixels) for easy viewing of measurement results, component symbols, and parameters.

Functionality

One-button operation for automatic component identification and measurement. It automatically detects the component type and pinout configuration.

Component Types

NPN/PNP transistors, N-channel/P-channel MOSFETs, JFETs, diodes (including dual diodes), thyristors, triacs, resistors, capacitors, and inductors.

Measurement Ranges

Capacitance: 25pF to 100mF (100,000µF) Resistance: 0.01Ω to 50MΩ Inductance: 0.01mH to 20H Diode/Zener: Forward voltage drop (up to 4.5V) and breakdown voltage (for Zener diodes).

Test Current

Low test current to prevent damage to sensitive components.

Power Source

Typically powered by a DC 9V battery or a Micro-USB port, making it portable.

Self-Calibration

Features a self-calibration function to ensure measurement accuracy.

Extra Features

Automatic shutdown to save power. Test points for component insertion. Backlight for the display. Built-in battery voltage detection.
