360 Degree Trajectory Ball Module Hall Effect Sensor حساس تتبع كره دائريه
|
Specification |
|
|
Sensor Type |
3D Hall Effect Sensor Array |
|
Detection Range |
Full 360° spherical coverage |
|
Resolution |
0.1° (angular) |
|
Output Interface |
I2C (default) / SPI (configurable) |
|
Data Rate |
Up to 1kHz |
|
Operating Voltage |
3.3V - 5V DC |
|
Current Consumption |
15mA (typical) |
|
Ball Diameter |
10mm (high-precision stainless
steel) |
|
Magnetic Field Range |
±50mT |
|
Nonlinearity |
<0.5% FSR |
|
Repeatability |
±0.05° |
|
Operating Temperature |
-40°C to +85°C |
|
Vibration Resistance |
50G (10-2000Hz) |
|
IP Rating |
IP54 (splash proof) |
|
Dimensions |
Φ24mm × 18mm |
|
Weight |
8g |
