SHF12 Horizontal Type Holder قاعدة تثبيت محور املس
-
$ 10,00
Reviews & Ratings
|
Description |
|
|
Model Designation |
SHF12 (A widely recognized
designation across manufacturers) |
|
Compatible Shaft Diameter (d) |
12mm (Specifically designed to
firmly clamp and support 12mm diameter linear shafts/rods) |
|
Type |
Horizontal Type Holder / Flanged
Shaft Support / Fixed End Support |
|
Material |
Aluminum Alloy (Typically
anodized, usually in silver or sometimes black, providing good corrosion
resistance and a durable finish) |
|
Mounting Orientation |
Horizontal mounting (Designed to
be bolted onto a flat surface, with the shaft extending horizontally,
parallel to the mounting plane) |
|
Overall Dimensions
(approx.) |
|
|
- Length (L) |
~47mm |
|
- Width (W) |
~28mm |
|
- Height (H) |
~12mm - 13.2mm (This refers to the
overall height from the base to the top of the clamping mechanism) |
|
- Mounting Hole Spacing (A) |
~36mm (Center-to-center distance
of the mounting holes on the base flange) |
|
- Mounting Hole Diameter (D) |
~5.5mm (Suitable for M5 screws,
which are the common fasteners used for mounting) |
|
Shaft Clamping Method |
Split Clamp Design with Set
Screw(s) (Typically one or two M4 or M5 grub/set screws are used to tighten
the split in the aluminum body, creating a strong friction clamp around the
12mm shaft) |
