Model Designation

SK10 / SH10 (These are common designations, often interchangeable between manufacturers)

Compatible Shaft Diameter (d)

10mm (designed to securely hold and support a 10mm diameter linear shaft/rod)

Type

Vertical Type Holder / Fixed End Support

Material

Aluminum Alloy (Typically anodized in silver or black for corrosion resistance and aesthetic finish)

Mounting Orientation

Vertical mounting (designed to be bolted onto a flat surface, with the shaft clamping upwards from the base)

Overall Dimensions (approx.)

- Width (W)

~42mm

- Height (H)

~28mm

- Length/Base (L)

~25mm

- Mounting Hole Spacing (A)

~32mm - 34mm

- Mounting Hole Diameter (D)

~5.5mm (for M5 screws)

Shaft Clamping Method

Split Clamp Design with Set Screw(s) (Usually one or two M4/M5 set screws are used to compress the split in the aluminum body, firmly gripping the shaft.)
