Measurement Principle

Ultrasonic Time-of-Flight (ToF)

Measurement Range

0.05m - 8m (5cm - 800cm)

Accuracy

±1cm (0.01-2m), ±0.5% FS (2-8m)

Resolution

1mm

Beam Angle

15° conical

Output Interface

RS485 (Modbus RTU protocol)

Baud Rate

9600/19200/38400/57600/115200 bps configurable

Operating Voltage

DC 9-36V (12V recommended)

Current Consumption

<30mA (idle), <60mA (measuring)

Response Time

50ms (typical)

Sampling Rate

20Hz max

Protection Rating

IP65 (dustproof & water jet resistant)

Housing Material

ABS+PC alloy (UV resistant)

Transducer Frequency

40kHz ±1kHz

Operating Temperature

-25°C to +70°C

Dimensions

Φ42mm × 85mm (barrel type)

Weight

150g
