Key Specifications Explained:

1.    Parallel Charging: Enables charging multiple batteries simultaneously at the same voltage level

2.    XT60 Standard: Robust connectors for high-current RC applications (up to 60A continuous)

3.    Fuse Protection: Individual fuses for each battery port prevent cross-circuit failures

4.    Voltage Matching: Requires batteries to be within 0.1V/cell difference before connecting

5.    Charger Compatibility: Works with any charger supporting LiPo balance charging protocols

Safety Notes:

Critical Requirements

·       Batteries must have same cell count (all 2S, all 3S, etc.)

·       Initial voltage difference ≤0.1V per cell

·       Never mix different capacity batteries

Always use fireproof charging containers
